| Width: | |
|---|---|
| Thickness: | |
| Quantity: | |
ZZ-R1050
Zhizheng
Product Features
Temperature Resistance
Synthetic resin tiles can withstand harsh weather conditions such as ultraviolet radiation and acid rain, are not easily faded or aged, and have a long service life.
Water Resistant
Resin tiles have a dense structure, low water absorption rate, significant waterproof effect, and can effectively prevent leakage.
Shock Resistant
Has high mechanical strength, can withstand impacts such as hail and heavy objects, and is not easily broken.
Fire Retarndant
It is usually a B1 level flame-retardant material that does not spread in the event of fire and has good fire resistance.
Thermal Insulation
Low thermal conductivity, effective insulation and heat preservation, reducing indoor and outdoor temperature differences, and improving building energy efficiency.
Excellent Corrosion Resistance
It has strong resistance to chemicals such as acids, bases, and salts, and is suitable for corrosive environments such as chemical and coastal areas.
Noise and Heat Insulation
It can effectively reduce noise such as raindrops and wind, providing a quiet indoor environment.
Green Recyclable
The materials are recyclable, and the production and use processes are environmentally friendly, meeting the requirements of green building
Long Lasting Color
We offer a variety of color options to meet the needs of different architectural styles, and the colors are long-lasting and never fade.
Easy Installation
Lightweight, easy to transport and install, reduces building load, lowers construction difficulty and costs
Product Structure
Product Parameters
 | Product Name | ASA Synthetic resin tiles |
| Material | PVC | |
| Width | 1050mm | |
| Available Width | 960mm | |
| Wave Height | 30mm | |
| Thickness | 2.3mm/2.5mm/2.8mm/3mm or Customized | |
| Color | Brick Red，Purplish Red，Iron Red，Skye Blue，Rose Red，Golden，Hot Red，Blue Grey，Dark Grey，Dark Gree or Customized |
Performance Index
Test Item | Unit symbol | Standard | Test Result | Judgment Result |
| Width deviation | mm | ±10.0 | -1 | Qualified |
| Thickness | mm | ≥2.8 | 2.98 | Qualified |
| Surface layer thickness | mm | ≥0.15 | 0.161 | Qualified |
Size change rate after heating | % | ±2.0 | 0.6 | Qualified |
Heating state(150℃，30 minutes) | / | No bubbles, cracks, or spots should be produced | Qualified | Qualified |
Low temperature drop hammer impact(-10℃,1kg,1.0m) | （个） | Number of ruptures≤1 | 0 | Qualified |
0xygen index | % | ≥32 | ≥33 | Qualified |
| Bearing performance(span 660mm,deflection 3%) | N | ≥800 | 1525 | Qualified |
| Stress cracking resistance | / | No cracks, no separation | Qualified | Qualified |
| Density | g/cm³ | ≤1.85 | 1.67 | Qualified |
Bending strength | MPa | ≥40 | 48 | Qualified |
| Bending modulus of elasticity | MPa | ≥2200 | 3150 | Qualified |
Tensile fracture strength | MPa | ≥20 | 27 | Qualified |
Nominal fracture strain | % | ≥15 | 65 | Qualified |
Notched impact strength of simply supported beams | KJ/㎡ | ≥40 | 110 | Qualified |
| Vicat softening temperature(B50) | ℃ | ≥75 | 84 | Qualified |
Accessories
Product Application
Company Introduction
Zhizheng has a large capacity in material modification, ex-trusion production and injection production, and focus on material modification and product manufacturing of functional polymer materials for specialized application fields.
QMS Certification
SGS Certification
Test Report
SGS Certification
FAQ
Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge ,there are delivery cost to be paid by buyer. |
Q: How long is your delivery time? A:General spot products are shipped within 5-7 days, while customized products take 30-45 days according to the required quantity. |
Q: How could you guarantee your products? A: Each piece of products is manufactured by certified workshops, inspected by zhizheng piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality. |
Q: Can we visit your factory? A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case. |
